Description
Product Overview
Up to 700mm/s With a maximum print speed of 700mm/s and acceleration up to 40,000mm/s², the SV08 delivers faster, high-quality results even for large-scale prints.
Product Details & Specifications
| 4× Print Volume With a generous printing volume of 350x350x345mm³, the expansive space ensures that creation needs to be caged. This freedom allows for the full expression of creativity, unbounded by the limitationsof smaller printing volumes. | |
| Built-in Camera SVO8 is equipped with a camera that allows monitoring of the printing process in real time. | |
| Additionally, it enables the capturing of time-lapse footage, which is the ability to closely observe and document the printing process, offering convenience and insight into the printing experience. | |
| All-axes Linear Rails SVO8 utilizes linear rails for all 7 axes (4Z+2Y+1X) to improve precision and resistance to axial movement deformation.The provision of smooth and precise linear motion is crucial for producing high-quality prints. | |
| These rails guide the printer’s print head and build platform, ensuring accurate positioning and consistent, smooth movement throughout the printing process. | |
| Remote Control Simply connect SV08 to your LAN using WiFi or an Ethernet port enables convenient interaction with your printers and grants access to a range of features. | |
| 4 Independent Z Motors The entire gantry system can be smoothly leveled using 4 independent Z motors. This process, known as Quad-Gantry-Leveling (QGL), enhances printer accuracy, reducing the likelihood of print failures. | |
| It can also detect and compensate for wear or damage. Efficient Heating Kit SV08 3D printer heats up rapidly, Ceramic Plate Heating & High-Flow Nozzle reach 300°C quickly and 220°C in 40 seconds. | |
| Using ceramic heating block & AC heated bed reduce heating time by 70%, allowing near-instant printing and easy preheating for nozzle cleaning and leveling. Enjoy precise, high-quality prints with versatile material compatibility. | |
| Specification Build Volume(W*D*H) 350*350*345mm³ Max Printing Speed 700mm/s Max Acceleration 40000mm/s² Flow Rate ≤30mm³/s Printing Accuracy ±0.1mm Layer Height 0.08-0.36mm Auto Leveling Method Inductive sensor & pressure sensor Connectivity Ethernet, Wi-Fi: 2.4 GHz (WPA2 only, WPA3 not supported) Nozzle Diameter 0.4mm (Include), 0.2mm, 0.6mm, 0.8mm Nozzle Temperature ≤300℃(572℉) Hot Bed Temperature ≤100℃(212℉) Filament Diameter 1.75mm Operation System Windows, Linux, Mac Printer Size 550*537*575mm (Includes Screen and Filament Holder) Power Supply 150W/24V Build Plate PEI Steel Plate Extruder Planetary gear extruder Camera Yes Filament Sensor Yes Compatible Slicer OrcaSlicer, Cura, PrusaSlicer, Simplify3d Supported Filament PLA, PETG, TPU, PETG-CF, ABS, etc. | |
| File Format Supported G-code System Architecture 64-bit CPU H616 RAM 1GB Flash Memory 8GB(EMMC) Stepper Driver TMC2209 |
